Adaptec SCSI Card 39320A-R
The Adaptec SCSI Card 39320A-R is a 64-bit 133 MHz PCI-X, dual-channel Ultra320 SCSI card with integrated HostRAID® RAID levels 0, 1, and 10. The Adaptec 39320A-R offers additional drivers for HostRAID as well as a new management tool. It provides worry-free data protection at the fastest SCSI speeds available up to 640 MByte/sec. The card has two 68-pin VHDCI external connectors and two 68-pin HD internal connectors for Ultra320 SCSI (LVD) hard disks drives.
Supported Operating Systems |
| Microsoft Windows Red Hat Linux SUSE Linux Novell NetWare Sun Solaris SCO Unix For a detailed list see ASK Answer ID 11061
|
Benefits |
| Dual-channel, Ultra320 card ideal for mid-range to enterprise servers requiring RAID mirroring or striping
|
Customer Needs |
| Ideal for mid-range to enterprise servers and workstations requiring entry-level data protection
|
System Environment |
| Server
|
RAID Levels |
| RAID 0, 1, 10
|
Number of devices |
| Up to 30 SCSI devices
|
Bus System Interface Type |
| 64-bit, 133 MHz PCI-X
|
External Connectors |
| Two 68-pin VHDCI
|
Internal Connectors |
| Two 68-pin Ultra320
|
Data Transfer Rate |
| 320 MByte/sec/channel
|
System Requirements |
| Intel PC or equivalent with available PCI slot (2.2 compliant)
|
