Toshiba MQ01ABD075 750GB 5400rpm 2.5" SATA Notebook Hard Drive

  • $63.00




Toshiba Storage Device Division offers a line of 5,400 RPM 2.5-inch HDDs in a new slim design optimized for industry-leading storage applications. The latest HDD series, MQ01ABDxxx, provides a wide capacity range from 250 GB to 1TB in a 9.5-millimeter-high design with only maximum 2 platters.

The advanced MQ01ABDxxx targets markets such as portable multimedia and gaming notebooks, mobile workstations and other capacity-hungry applications like external HDDs. In addition, the drives also feature very good power efficiency value of 0.00055 for the 1TB model. Due to the ?Silent-Seek? technology featured in these drives, the HDDs are extremely quiet: Ultra-silent single-platter drives boast acoustic specifications of 19dBA (seek) and 17dBA (idle) making them almost indistinguishable to the human hear.

With its compact size and best-in class specifications, the SATA MQ01ABDxxx series is the perfect choice for use in devices where a combination of sleek form factor and high capacity capabilities are essential.

As with all Toshiba HDDs, the complete series is halogen-free and RoHS compatible, therefore, exceptionally environmentally friendly.


Model MQ01ABD025 MQ01ABD032 MQ01ABD050 MQ01ABD064 MQ01ABD075 MQ01ABD100
Formatted capacity 250 GByte 320 GByte 500 GByte 640 GByte 750 GByte 1000 GByte
Form factor                                           2.5 inch
Interface type Serial ATA
Supported interface standards

ATA-8 Serial ATA 2.6

Shock detection Shock sensor circuit

The SMART command set is supported.

Physical parameters
Number of platters 1 1 1 2 2 2
Number of heads 2 2 2 4 4 4
Bytes/sector (Host)


Bytes/sector (Disk)

4096 kByte

Access times
Average seek time

12 ms

Maximum seek time

22 ms

Track-to-track seek time

2 ms

Transfer rates
SATA (Host) max. 3.0 Gbit/s
Rotational speed

5,400 rpm

Buffer size

8,192 kByte

Reliability specifications
MTTF 600,000 Hours
Seek error rate 1 error per 106 seeks
Non-recoverable error rate 1 error per 1014 seeks
Power consumption
Start (Maximum) 4.5 W
Seek (Average) 1.85 W
Read (Average) 1.5 W
Write (Average) 1.5 W
Low-power idle (Average) 0.55 W
Sleep (Average) 0.15 W
Stand-by (Average) 0.18 W
Power supply
Supply voltage

+5 V (+/- 5 %)

Drive orientation

The drive can be installed in all axes (6 directions)


From 5 ?C to 55 ?C


From -40 ?C to 65 ?C


From 8 % to 90 %


From 8 % to 90 %

Operating (Maximum)

1 G, with 5 - 500 Hz

Non-operating (Maximum)

5 G, with 15 - 500 Hz

Operating (Maximum)

400 G, with 2 ms half sine wave

Non-operating (Maximum)

900 G, with 1 ms half sine wave

Acoustic noise
Idle mode (Disk spinning) Max. 17 dB Max. 17 dB Max. 17 dB Max. 23 dB Max. 23 dB Max. 23 dB
Random seek Max. 19 dB Max. 19 dB Max. 19 dB Max. 24 dB Max. 24 dB Max. 24 dB
